Slab on Grade Analysis and DesignAutomatic Soil Springs, Soil Pressure and Uplift Checks in GSE™

How GSE™ models soil-structure interaction under a slab on grade with compression-only Winkler springs, checks soil pressure, uplift and deflection, and designs the reinforced concrete slab to ACI 318 or CSA A23.3.

Soil-structure interaction plays an important role in the design of buildings and structures. To make slab on grade modeling faster, GSE™ includes an automatic slab on grade generation function that distributes the stiffness of the soil to the finite element slab as equivalent springs.

In short
  • The soil is modeled as compression-only Winkler springs at the nodes of the plate elements that form the raft.
  • Each spring's stiffness comes from the soil's subgrade modulus and the node's tributary area, calculated automatically.
  • GSE™ gives nodal displacements, soil pressure under the slab and uplift for every load combination.
  • The slab is then designed in GSE™ Concrete to ACI 318 or CSA A23.3: bending reinforcement, shear and punching.

Soil-Structure Interaction for Slabs on Grade

With the slab on grade function, you can fully analyze and design a slab on grade in the 3D model and design it with the reinforced concrete tools of GSE™ Concrete. It is especially useful for slabs with complex geometries, where calculating the soil support by hand would take a long time.

GSE™ slab on grade
Slab on grade finite element model with soil springs in GSE structural software
Slab on grade modeled in GSE™, with the soil stiffness distributed to the slab as equivalent springs.

Modeling the Soil with Compression-Only Winkler Springs

The soil is modeled as a Winkler spring that works in compression only. Its rigidity is assigned to the joints of the plate elements that form the raft, so every node of the slab is supported by its own spring.

Subgrade modulus and tributary area

The equivalent rigidity of each spring depends on the subgrade modulus of the soil and on the tributary area of the node. GSE™ calculates the tributary area of every node automatically, so you don't have to work it out by hand, even on irregular slab shapes.

Supports You Can Combine with the Slab on Grade

The slab on grade can be combined with the other support conditions available in GSE™:

  • Ground springs
  • Regular springs
  • Fixed supports
  • Piles
  • Imposed displacements

Soil Pressure, Uplift and Foundation Flexibility

The analysis is run for the various load combinations of the project. GSE™ then gives the results you need to verify the slab and the soil:

Nodal displacements

The displacements of each node are used to check the stability and the deflection of the slab.

Soil pressure under the slab

The soil pressure is calculated from the nodal displacement, the spring stiffness and the tributary area. These results confirm that the foundation is sized so that the bearing capacity of the soil is not exceeded.

Uplift

Because the springs are unidirectional and work in compression only, the analysis lets you check the slab for uplift.

Foundation flexibility

The finite element method takes into account the flexibility of the foundation and its effect on the behaviour of the structure.

What GSE™ Checks on a Slab on Grade

CheckBased on
StabilityNodal displacements for each load combination
DeflectionNodal displacements for each load combination
Soil bearing capacitySoil pressure from displacement, stiffness and tributary area
UpliftCompression-only (unidirectional) soil springs
BendingLongitudinal reinforcement, GSE™ Concrete
ShearGSE™ Concrete shear verification
PunchingGSE™ Concrete punching verification

Slab on Grade Design to ACI 318 and CSA A23.3

Once the analysis is done, the slab on grade is designed with GSE™ Concrete, the reinforced concrete design module of GSE™, to the American or Canadian concrete standard:

  • USACI 318
  • CACSA A23.3
  • Bending: the longitudinal reinforcement is calculated from your design parameters.
  • Shear and punching: shear and punching shear are verified.
  • 3D reinforcement view: the reinforcement can be displayed in 3D on the slab.
GSE™ Concrete
Slab on grade reinforcement design in GSE Concrete to ACI 318 and CSA A23.3
Slab on grade reinforcement design in GSE™ Concrete.

Frequently Asked Questions

How does GSE™ model the soil under a slab on grade?

The soil is modeled as Winkler springs that work in compression only. GSE™ assigns a spring to each node of the plate elements that form the raft, with a stiffness based on the soil's subgrade modulus and the node's tributary area.

Do I have to calculate the tributary area of each node?

No. GSE™ calculates the tributary area of every node automatically, which is especially useful for slabs with complex geometries.

How is the soil pressure under the slab calculated?

The soil pressure is calculated from the nodal displacement, the spring stiffness and the tributary area. It is used to make sure the bearing capacity of the soil is not exceeded.

Can GSE™ check uplift of a slab on grade?

Yes. Because the soil springs are unidirectional and work in compression only, the analysis lets you check the slab for uplift.

Can I combine a slab on grade with piles?

Yes. The slab on grade can be combined with ground springs, regular springs, fixed supports, piles and imposed displacements.

Which design codes are used to design the slab?

The slab is designed with GSE™ Concrete to ACI 318 (US) or CSA A23.3 (Canada), with bending reinforcement, shear and punching shear checks.

Learn More

GSE™ Concrete

Analyze and Design Your Slab on Grade in GSE™

Automatic soil springs, soil pressure and uplift checks, and reinforced concrete slab design to ACI 318 and CSA A23.3, in the same 3D model.
