Fatigue limit state
HSE Features - Highway Sign Structural Engineering
TECHNICAL FEATURE // HSE SOFTWARE: FATIGUE LIMITE STATE
The HSE – Highway Sign Structural Engineering software includes the fatigue limit state.
The HSE software allows for Fatigue verification according to chapter 11 of AASHTO LTS-13 (ASD) and AASHTO LTS-15 (LRFD) and Stress verification according to the Constant Amplitude Fatigue Threshold (CAFT).
The CAFT (Constant Amplitude Fatigue Threshold) for infinite life for the different fatigue detail categories are found in AASHTO LTS-13 (ASD) Table 11.9.3.1-1 and AASHTO LTS-15 (LRFD) Table 11.9.3.1-1.
To enhance productivity and ease of use of the HSE software, HSE users can efficiently set and edit all required fatigue parameters for a structure allowing to consider all applicable fatigue loads such as Galloping, Natural Wind Gust, or Truck-Induced Gust.
The HSE software allows for Fatigue verification according to chapter 11 of AASHTO LTS-13 (ASD) and AASHTO LTS-15 (LRFD) and Stress verification according to the Constant Amplitude Fatigue Threshold (CAFT).
The CAFT (Constant Amplitude Fatigue Threshold) for infinite life for the different fatigue detail categories are found in AASHTO LTS-13 (ASD) Table 11.9.3.1-1 and AASHTO LTS-15 (LRFD) Table 11.9.3.1-1.
To enhance productivity and ease of use of the HSE software, HSE users can efficiently set and edit all required fatigue parameters for a structure allowing to consider all applicable fatigue loads such as Galloping, Natural Wind Gust, or Truck-Induced Gust.
HSE Software
The HSE highway sign structural engineering software is an automated structural program for the analysis and design of highway overhead structural sign supports, traffic signal supports, high-mast lighting towers and poles.
