Introducing the animation feature in SAFI Software.
The SAFI Software allows users to animate results from different types of analysis such as:
-Static Linear Analysis
-Static P-Delta Analysis
-Buckling Analysis
-Natural Frequencies Analysis
-Seismic and Dynamic Analysis
In SAFI, users are able to animate various static linear and P-Delta analysis results such as the:
– Structure displacements
– Internal forces
– Stresses
– Support reactions
The results are scaled by a linearly increasing factor until the unity factor is reached. The user can detect which parts of the model undergo the most displacements or internal forces by seeing the variation of intensity across the model.
Animating the envelopes helps minimizing the amount of information on the screen. The user can focus on the most critical regions of the model.
In the bridge results menu (BSE Bridge Structural Engineering), animating the envelopes helps minimizing the amount of information on the screen. The user can focus on the most solicited regions of the model. As the animation evolves, the final results are displayed and the global envelopes are displayed.
The animation function displays every saved time-step to provide an accurate representation of the displacements, velocities, accelerations and internal forces acting on the structure.
This will provide the user a better understanding of the structure behavior during the dynamic event, such as finding the critical time of the dynamic loading.
To enhance productivity of GSE Timber software’ users, the Anchorage Elongation Method can be defined as variable (tension only) and variable (tension and compression). The anchorage slip is calculated at each iteration according to the tension efforts at the anchorage locations.
HSE users can efficiently set and edit all required fatigue parameters for the structure allowing to consider all applicable fatigue loads such as Galloping, Natural Wind Gust, or Truck-Induced Gust.
The live load reduction is available for the GSE steel, concrete, aluminum, and wood modules. The live load reduction will be applied to the columns of the structure.
Live loads can be automatically reduced according to the selected method. The software computes the live load reduction factor (LLRF) that will reduce the effective axial compression force in columns.
The resistance limit states, under fire conditions, are calculated for large cross-section wood elements. To improve the productivity of GSE users, the elements cross-sections are automatically reduced during the limit state checks.
